A complete three-product floor system that waterproofs from the screed up, applies a non-slip surface coating and seals it with a hardened protective finish. The result is a floor that is waterproof, safe underfoot and tough enough for service areas, commercial floors, pool surrounds and wet areas.
WATERPROOFING SYSTEM
COMPOSITION OF THE ARMTEC HYPERFLEX - NON-SLIP FLOOR SYSTEM
Five layers — each with a specific job. Penetrar binds the screed. HyperFlex embeds the reinforcing mesh. HydroSeal HF delivers the waterproof membrane. GripGuard applies the non-slip surface. Clear Coat P2UD locks and hardens the finish. Together they deliver a floor that is waterproof, safe and built for long-term heavy use.
Application Steps
1/ CONCRETE
CLEAN - Remove all debris, dust and loose material. Surface must be clean, dry and sound
2/ PENETRAR
BIND & PRIME - Applied to the concrete or screed floor surface — binds dust, stabilises the substrate and maximises adhesion for all layers above. On a porous floor, Penetrar keeps the polymer content of the waterproofing layers in the top layer where it performs best.
3/ ARMTEC MESH
REINFORCE - Fibreglass reinforcing mesh rolled out across the full floor surface — distributes stress and absorbs any movement or settlement in the screed below the waterproof membrane.
4/ HyperFlex
BOND MESH TO FLOOR - Applied over the mesh and pressed through to bond it permanently to the Penetrar-primed floor below — locking the reinforcing layer in place before the waterproof membrane is applied.
5-6/ StretchSeal Membrane + HydroSeal HF
REINFORCE CORNERS & TURNUPS - All wall turnups and floor-to-wall junctions reinforced — HydroSeal HF applied, StretchSeal Membrane embedded, second coat HydroSeal HF to encapsulate. Every vulnerable detail point sealed before the full topcoat is applied.
7/ HydroSeal HF
WATERPROOF — 2 X COATS - First coat of seamless liquid rubber membrane applied over the entire floor system once touch dry and walkable. Final coat completes the seamless waterproof membrane once the first coat is completely dry — fully bonded, UV stable, the base the non-slip system bonds to.
8/ GripGuard
NON-SLIP COAT - Applied directly over the cured HydroSeal HF — delivers the non-slip surface texture that makes the floor safe underfoot in wet conditions. Available in 12 colour options.
9/ Clear Coat P2UD
HARDEN & SEAL - Applied over the cured GripGuard — seals and hardens the non-slip surface, making it more durable under foot traffic, easier to clean and resistant to surface wear. Milky white in the container, dries to a clear low-sheen hardened finish.
HOW IT WORKS
A FLOOR THAT IS WATERPROOF, SAFE UNDERFOOT AND BUILT FOR HEAVY USE.
Most floor coatings solve one problem. This system solves three — simultaneously. The ArmTec HyperFlex base waterproofs the screed from the ground up, creating a seamless membrane that protects the substrate below from water damage permanently. GripGuard delivers the non-slip surface texture that makes the floor safe in wet conditions. And Clear Coat P2UD hardens and seals the entire surface — significantly extending the working life of the system under foot traffic, cleaning chemicals and daily service area use.
The three products are designed to work together. HydroSeal HF provides the stable, fully bonded base GripGuard bonds to. Clear Coat P2UD locks in the GripGuard surface colour and texture — protecting it from wear and making it easier to maintain over time. The result is a floor system where every layer reinforces the one above it.
Renew or maintain your current waterproofing system without removing it. The Armtec Renew system has excellent adhesion and can be applied directly over existing waterproofing systems. The Armtec Renew system can be applied directly onto bituminous substrates or existing torchon membrane. Surface will not delaminate when correct application procedures has been adhered to.
The seamless eco-friendly concrete roof slab waterproofing system from SealPro Coatings can be installed on new and existing roof slabs. The waterproofing system is a high-performance universal waterproofing system specifically developed for long term protection. Applying the SealPro waterproofing system will guarantee a seamless waterproofing system that is UV resistant and durable.
Balconies, like all other parts of a property, require waterproofing. Whether the balcony is constructed using a concrete slab or timber, if water has penetrated the top surface, it will find or cause weakness. This will result in water damage to the ceiling or walls below. The solution to this problem is to waterproof the balcony. Explore the Armtec under-tile waterproofing systems for more information.
The tile roof waterproofing system is used to waterproof roof ridge, valley, flashing & parapet walls. The system will seal your roof and help protect against leaks and weathering. The tile roof waterproofing system is UV stable, weather-resistant, durable, long-lasting and low maintenance.
Our approach to restoring and waterproofing metal roofs offers a long-term solution, with no exposure of brittle materials to the elements, providing you with a leak-free roof for years to come. The waterproofing system can be used to seal ridges, valleys, joints, overlaps & screwlines.
The waterproofing system can be used to seal ponds, cement dams, water features, birdbaths and fountains. When fully cured the waterproofing system forms an impervious, flexible and aesthetically pleasing waterproofing membrane which enhances the look of the pond or water feature.
The success of any project depends on the type of product and the correct application of the solution. The SealPro technical support team has experience in all specialised coatings we supply and can help you to find the correct product & solution for your application.
